288 FO OM3 / OM4 / OS2 / G657 MULTITUBE LOOSE ARMED EXT PE
FIBRE OPTICS |
Construction
Central Element:
Fibres Nb: 288
Identification: According to TIA/EIA 598A and IEC 304.
Assembly:
Protector: Glass fibre fillings.
Armour: Corrugated steel tape.
Outer cover: UNE-EN 50290-2-27 - Halogen-free Z1 compound.
Color: Black
UV resistant
Rodent protection
Mechanical protection
CE
Low smoke opacity
RoHS
CPR Compilant
Halogen free
Weather resistantTechnical data / Regulations.
CPR classification: Eca
Operating temperature: -30... +70ºC
Standards:
(Sheath) UNE-EN 50290-2-27 - Halogen-free Z1 compound.
(Fire) UNE-EN 50575 - CPR
(Fire) UNE-EN 60754-2 (IEC 60754-2) - Low corrosivity of smoke.
(Fire) UNE-EN 60332-1 (IEC 60332-1) - Flame-retardant.
(Fire) UNE-EN 61034 (IEC 61034) - Low smoke emission.
(Fire) UNE-EN 60754-1 (IEC 60754-1) - Halogen-free.
(Tests) IEC 60794-1 - Basic test procedures for optical cables.
(Tests) IEC 60794-1-21 -
(Tests) IEC 60794-1-22 -
(Directives) 2011/65/EU - RoHS Directive (No use of toxic products).
(System) UNE-EN 50173-1 - Information technology - Generic cabling systems - Part 1: General requirements.
(System) TIA/EIA 568C - Structured Cabling System
(System) ISO/IEC 11801 Edition 2 - Information technology -- Generic cabling.
Observations
Ceramic loose tube Ø 2.5 mm.
MULTIMODE fibers type 50/125 OM3 / OM4.
SINGLE MODE fibers type 9/125 SO2 / G657.
Applications
Gel-filled loose multitube Fiber Optic Cable filled with fiberglass strands + corrugated steel metal armor and PE outer sheath for outdoor installations.
Cables up to 288 fibers, MULTIMODE or MONOMODE type.
Resistant to the action of rodents.
